Specifications | ||||||||||||||||||||||||||||
Product code | C53UiG+5HPaxD2HPaxD | |||||||||||||||||||||||||||
Architecture | ARM 64bit | |||||||||||||||||||||||||||
CPU | IPQ-6010 | |||||||||||||||||||||||||||
CPU core count | 4 | |||||||||||||||||||||||||||
CPU nominal frequency | auto (864 - 1800) MHz | |||||||||||||||||||||||||||
Switch chip model | IPQ-6010 | |||||||||||||||||||||||||||
RouterOS license | 6 | |||||||||||||||||||||||||||
Operating System | RouterOS v7 | |||||||||||||||||||||||||||
Size of RAM | 1 GB | |||||||||||||||||||||||||||
Storage size | 128 MB | |||||||||||||||||||||||||||
Storage type | NAND | |||||||||||||||||||||||||||
MTBF | Approximately 200'000 hours at 25C | |||||||||||||||||||||||||||
IPsec hardware acceleration | Yes | |||||||||||||||||||||||||||
Tested ambient temperature | -40°C to 70°C | |||||||||||||||||||||||||||
Powering | ||||||||||||||||||||||||||||
Number of DC inputs | 2 (DC jack, PoE-IN) | |||||||||||||||||||||||||||
DC jack input Voltage | 12-28 V | |||||||||||||||||||||||||||
Max power consumption | 38 W | |||||||||||||||||||||||||||
Max power consumption without attachments | 15 W | |||||||||||||||||||||||||||
Cooling type | Passive | |||||||||||||||||||||||||||
PoE in | Passive PoE | |||||||||||||||||||||||||||
PoE in input Voltage | 18-28 V | |||||||||||||||||||||||||||
Ethernet | ||||||||||||||||||||||||||||
10/100/1000 Ethernet ports | 4 | |||||||||||||||||||||||||||
Number of 1G Ethernet ports with PoE-out | 1 | |||||||||||||||||||||||||||
Number of 2.5G Ethernet ports | 1 | |||||||||||||||||||||||||||
Peripherals | ||||||||||||||||||||||||||||
Number of USB ports | 1 | |||||||||||||||||||||||||||
USB Power Reset | Yes | |||||||||||||||||||||||||||
USB slot type | USB 3.0 type A | |||||||||||||||||||||||||||
Max USB current (A) | 1 | |||||||||||||||||||||||||||
Certification & Approvals | ||||||||||||||||||||||||||||
Certification | CE, FCC, IC, EAC, ROHS | |||||||||||||||||||||||||||
PoE-out | ||||||||||||||||||||||||||||
PoE-out ports | Ether 1 | |||||||||||||||||||||||||||
PoE out | Passive PoE | |||||||||||||||||||||||||||
Max out per port output (input 18-30 V) | 0.625 A | |||||||||||||||||||||||||||
Max total out (A) | 0.625 A | |||||||||||||||||||||||||||
Total output current | 0.625 | |||||||||||||||||||||||||||
Total output power | 15 | |||||||||||||||||||||||||||
Other | ||||||||||||||||||||||||||||
CPU temperature monitor | Yes | |||||||||||||||||||||||||||
Mode button | Yes | |||||||||||||||||||||||||||
Wireless specifications | ||||||||||||||||||||||||||||
2.4 GHz TX/RX |
| |||||||||||||||||||||||||||
5 GHz TX/RX |
| |||||||||||||||||||||||||||
Wireless 2.4 GHz Max data rate | 574 Mbit/s | |||||||||||||||||||||||||||
Wireless 2.4 GHz number of chains | 2 | |||||||||||||||||||||||||||
Wireless 2.4 GHz standards | 802.11b/g/n/ax | |||||||||||||||||||||||||||
Antenna gain dBi for 2.4 GHz | 3.3 | |||||||||||||||||||||||||||
Wireless 2.4 GHz chip model | QCN-5022 | |||||||||||||||||||||||||||
Wireless 2.4 GHz generation | Wi-Fi 6 | |||||||||||||||||||||||||||
WiFi speed | AX1800 | |||||||||||||||||||||||||||
Wireless 5 GHz Max data rate | 1200 Mbit/s | |||||||||||||||||||||||||||
Wireless 5 GHz number of chains | 2 | |||||||||||||||||||||||||||
Wireless 5 GHz standards | 802.11a/n/ac/ax | |||||||||||||||||||||||||||
Antenna gain dBi for 5 GHz | 5.5 | |||||||||||||||||||||||||||
Wireless 5 GHz chip model | QCN-5052 | |||||||||||||||||||||||||||
Wireless 5 GHz generation | Wi-Fi 6 |
